Raypak R405 Burner Tray Without Burner [Sea Level] (005220F)

This Raypak R405 Burner Tray Without Burner [Sea Level] is intended for service work on compatible Raypak pool and spa heaters where the burner tray section must be replaced, rebuilt, or converted back to a dependable factory-style configuration. The burner tray is a central combustion-area component, so matching the model, fuel type, elevation note, and ignition style is essential before installation. Part 005220F is best used when corrosion, heat fatigue, gas valve issues, burner wear, or prior repair work has made the existing tray unreliable.

Because Raypak burner tray assemblies are model- and fuel-specific, this item should be compared carefully with the heater data plate and the existing assembly before purchase. This version is built around specified gas use and the listed ignition configuration, and it is supplied without burner, allowing reuse of compatible burner components. Professional installation is strongly recommended for gas train, burner, and ignition-related repairs, especially when working with older Raypak R-series and residential heater platforms.

• Replacement burner tray component for the Raypak model/application shown in part 005220F
• Designed for specified gas heater configurations and the listed ignition configuration
• Useful when servicing combustion-area wear, corrosion, damaged burner supports, or valve-related repairs
• Helps restore proper burner positioning, flame stability, and heater serviceability when correctly matched
• Confirm heater model, fuel type, ignition system, elevation rating, and existing part number before ordering
